The Apollo Lunar Module (LM), originally designated the Lunar Excursion Module (LEM), was the first crewed spacecraft to land on the Moon. It was flown between lunar orbit and the Moon's surface during the United States' Apollo programme. The LM was a two-stage vehicle, with separate engines and tanks for landing and ascent. The descent stage contained two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, and storage space for lunar equipment and experiments. The ascent stage housed the astronauts in a pressurised crew compartment and returned them to the CSM. So, how much fuel did the lunar module have?
| Characteristics | Values |
|---|---|
| Name | Lunar Module Eagle (LM-5) |
| Other Names | Lunar Excursion Module (LEM), Apollo LM Truck, Lunar Payload Module (LPM) |
| Organization | Apollo |
| Mission | Apollo 11 |
| Crew | Neil A. Armstrong, Edwin E. "Buzz" Aldrin, Jr. |
| Fuel | Aerozine 50, propellant, nitrogen tetroxide |
| Fuel Tank Size | 4 feet in diameter and about 6 feet in length |
| Fuel Weight | 53,000 lbs |
| Fuel Volume | 6380 gallons |
| Fuel Tank Volume | 4ft high by 90ft long |
| Power Source | Fuel cells, batteries |
| Number of Legs | Four |
| Distance Between Footpads | 9.4 m |
Explore related products
What You'll Learn
- The Lunar Module's descent stage contained two tanks of aerozine 50 fuel
- The Lunar Module ascent stage had enough fuel to return to the CSM
- The Lunar Module's descent stage was mostly fuel tanks
- The Lunar Module had separate tanks for landing and ascent
- The Lunar Module weighed 53,000 pounds, most of which was fuel
The Lunar Module's descent stage contained two tanks of aerozine 50 fuel
The Apollo Lunar Module (LM), originally designated the Lunar Excursion Module (LEM), was a two-stage vehicle with separate engines and tanks for landing and ascent. The Lunar Module descent stage contained two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, and tanks of water, oxygen, and helium. The descent stage also contained storage space for lunar equipment and experiments, and in the case of Apollo 15, 16, and 17, the lunar rover.
The Lunar Module descent stage served as a platform for launching the ascent stage and was left behind on the Moon. The ascent stage, on the other hand, housed the astronauts in a pressurized crew compartment. This compartment had a volume of 6.65 cubic meters and functioned as the base of operations for lunar operations.
The Lunar Module descent engine was a deep-throttling ablative rocket with a maximum thrust of about 45,000 N, mounted on a gimbal ring in the center of the descent stage. The ascent engine, in comparison, was a fixed, constant-thrust rocket with a thrust of about 15,000 N. The Lunar Module's total fuel weight, including both the descent and ascent stages, was approximately 53,000 pounds.
The Apollo 11 Lunar Module, also known as Eagle, was the first crewed vehicle to land on the Moon. It was flown by astronaut Neil Armstrong, with navigational assistance from Buzz Aldrin. The successful landing of Eagle on the Moon's surface marked the historic moment when humans first set foot on another world, expanding our horizons and knowledge of the universe beyond Earth.
Fueler Trucks: HEMTT Fueler Costs and Capabilities
You may want to see also
Explore related products
The Lunar Module ascent stage had enough fuel to return to the CSM
The Lunar Module (LM) was a two-stage vehicle with separate engines and tanks for landing and ascent. The descent stage contained the landing rocket, two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, water, oxygen, helium tanks, and storage space for lunar equipment and experiments. The ascent stage housed the astronauts in a pressurised crew compartment and served as the base of operations for lunar operations.
The LM was flown between lunar orbit and the Moon's surface during the United States' Apollo program. It was the first crewed spacecraft to operate exclusively in space and remains the only crewed vehicle to land anywhere beyond Earth. The LM was structurally and aerodynamically incapable of flight through Earth's atmosphere. It was ferried to lunar orbit attached to the Apollo command and service module (CSM), about twice its mass.
The LM ascent stage had enough fuel to return to the CSM. During takeoff, the spent descent stage was used as a launchpad for the ascent stage, which then flew back to the command module and was discarded. The ascent engine was a fixed, constant-thrust rocket with a thrust of about 15,000 N. The ascent stage could also accommodate the weight of the lunar samples brought back by later missions, which fell within the ascent stage fuel margins.
The Apollo 11 LM, named Eagle, was the first crewed vehicle to land on the Moon. It carried two astronauts, Commander Neil A. Armstrong and LM pilot Edwin E. "Buzz" Aldrin, Jr., the first men to walk on the Moon. Eagle entered lunar orbit on July 19, 1969, and landed on the Moon on July 20, 1969.
Liquid Hydrogen Fuel: Cost Analysis
You may want to see also
Explore related products
$204.99 $215.99
The Lunar Module's descent stage was mostly fuel tanks
The Lunar Module Eagle (LM-5) was the first crewed lunar lander of Apollo 11, which was the first mission to land humans on the Moon. The Lunar Module was a two-stage vehicle, with separate engines and tanks for landing and ascent. The descent stage was mostly fuel tanks, containing two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, and tanks of water, oxygen, and helium. The Lunar Module also included the Early Apollo Scientific Experiment Package (EASEP), which consisted of several self-contained experiments to be deployed and left on the lunar surface, as well as other scientific and sample collection apparatus. The descent stage served as a platform for launching the ascent stage and was left behind on the Moon.
The Lunar Module descent stage contained the landing rocket and provided storage space for lunar equipment and experiments. The descent engine was a deep-throttling ablative rocket with a maximum thrust of about 45,000 N mounted on a gimbal ring in the center of the descent stage. The ascent stage, on the other hand, housed the astronauts in a pressurized crew compartment and functioned as the base of operations for lunar operations. The ascent engine was a fixed, constant-thrust rocket with a thrust of about 15,000 N.
The Lunar Module was originally designated the Lunar Excursion Module (LEM) and was overseen by Grumman during its development. The name was changed to Lunar Module (LM) in June 1966 to eliminate the word "excursion," as NASA was concerned that it might lend a frivolous note to the Apollo program. The Lunar Module was structurally and aerodynamically incapable of flight through Earth's atmosphere and had to be ferried to lunar orbit attached to the Apollo command and service module (CSM).
The final landing phase of the Apollo Lunar Module began about 2,000 feet (0.61 km) uprange of the targeted landing site. At this point, manual control was enabled for the commander, who had enough propellant to hover for up to two minutes to survey the landing site and make any necessary corrections. The Lunar Module descent stage contained enough fuel to support the landing and provide a platform for launching the ascent stage.
Fuel Truck Weights: Understanding the Basics
You may want to see also
Explore related products
The Lunar Module had separate tanks for landing and ascent
The Apollo Lunar Module (LM) was the first crewed spacecraft to operate exclusively in space. It was also the first and remains the only crewed vehicle to land anywhere beyond Earth. The LM was a two-stage vehicle with separate engines and tanks for landing and ascent. The Lunar Module descent stage contained two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, and tanks of water, oxygen, and helium. The descent stage also contained storage space for lunar equipment and experiments. The ascent stage was an irregularly shaped unit approximately 2.8 m high and 4.0 by 4.3 meters in width mounted on top of the descent stage. The ascent stage housed the astronauts in a pressurized crew compartment with a volume of 6.65 cubic meters, which served as the base of operations for lunar operations.
The Lunar Module was structurally and aerodynamically incapable of flight through Earth's atmosphere. It was ferried to lunar orbit attached to the Apollo command and service module (CSM), about twice its mass. The LM's crew of two flew the craft from lunar orbit to the Moon's surface. During takeoff, the spent descent stage was used as a launchpad for the ascent stage, which then returned to the CSM and was subsequently discarded. The ascent stage was launched from the Moon at the end of lunar surface operations and returned the astronauts to the CSM.
The Lunar Module descent engine was a deep-throttling ablative rocket with a maximum thrust of about 45,000 N mounted on a gimbal ring in the center of the descent stage. The ascent engine was a fixed, constant-thrust rocket with a thrust of about 15,000 N. The LM's development was overseen by Grumman but was plagued with problems. The initial design had three landing legs, the lightest possible configuration, but this was unstable if one of the legs was damaged. The final design had four landing legs, a compromise between stability and weight.
The Apollo 11 LM, named Eagle, was the first crewed vehicle to land on the Moon. It was flown by astronaut Neil Armstrong with navigational assistance from Buzz Aldrin. The name of the craft gave rise to the famous phrase "The Eagle has landed", spoken by Armstrong upon Eagle's touchdown. The Eagle landed on July 20, 1969, creating Tranquility Base, named by Armstrong and Aldrin.
Fuel Costs in Oregon: How Expensive Is It?
You may want to see also
Explore related products
The Lunar Module weighed 53,000 pounds, most of which was fuel
The Apollo Lunar Module Eagle (LM) was the first crewed spacecraft to land on the Moon. It was part of the Apollo 11 mission and was flown by astronaut Neil Armstrong, with assistance from Buzz Aldrin. The Lunar Module weighed 53,000 pounds, most of which was fuel.
The Lunar Module was a two-stage vehicle, with separate engines and tanks for landing and ascent. The descent stage contained the landing rocket, two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, water, oxygen, helium tanks, and storage space for lunar equipment and experiments. The ascent stage housed the astronauts in a pressurized crew compartment and served as the base of operations for lunar operations.
The Lunar Module's development was plagued with problems, and its weight was a significant concern. The initial design had three landing legs, the lightest possible configuration, but this was unstable if one of the legs was damaged. The next design had five legs, but it was too heavy. The final design compromised with four landing legs.
The Lunar Module's fuel system was crucial to its success. During the final landing phase, the commander had enough propellant to hover for up to two minutes to make any necessary corrections. The descent engine had a maximum thrust of about 45,000 N, while the ascent engine had a constant thrust of about 15,000 N. The ascent stage had enough fuel margins to accommodate the increasing weight of lunar samples returned by later missions.
Walking: Saving Fossil Fuels, One Step at a Time
You may want to see also
Frequently asked questions
The Lunar Module Eagle (LM-5) had two tanks of aerozine 50 fuel, two tanks of nitrogen tetroxide oxidizer, and tanks of helium, liquid oxygen, and gaseous oxygen. The total weight of the fuel was 53,000 lbs.
The Lunar Module Eagle was the first crewed spacecraft to operate exclusively in space and remains the only crewed vehicle to land anywhere beyond Earth. It was the lunar lander spacecraft flown between lunar orbit and the Moon's surface during the United States' Apollo program.
The Lunar Module was a two-stage vehicle, with separate engines and tanks for landing and ascent. The descent stage served as a platform for launching the ascent stage and was left behind on the Moon.
The descent stage contained the landing rocket, fuel and oxidizer tanks, water, oxygen, helium tanks, and storage space for lunar equipment and experiments. It also served as a launchpad for the ascent stage during takeoff.
The ascent stage housed the astronauts in a pressurized crew compartment and functioned as the base of operations for lunar operations. It returned the astronauts back to the Command Module after completing their mission on the Moon.
