The Space Shuttle external tank (ET) was the largest element of the Space Shuttle and contained liquid hydrogen fuel and liquid oxygen oxidizer. The ET was the backbone of the shuttle during launch, providing structural support for attachment with the Space Shuttle Solid Rocket Boosters (SRBs) and the orbiter. The SRBs and the orbiter had a secondary, hypergolic fuel (hydrazine) that powered hydraulic systems and provided thrust vectoring. The ET also had electrical umbilicals that carried electrical power from the orbiter to the tank and the SRBs, as well as external cameras and transmitters that continued to send video data after separation. The amount of fuel in the ET varied depending on the configuration, but it typically held around 535,000 gallons (2 million liters) of fuel.
| Characteristics | Values |
|---|---|
| Name of the Space Shuttle external tank (ET) | "Backbone" of the shuttle |
| Components | Liquid hydrogen fuel, liquid oxygen oxidizer |
| Weight | Heaviest when loaded |
| Capacity | 629,340 kg (1,387,457 lb) of cryogenic liquid oxygen (LOX) and 106,261 kg (234,265 lb) of cryogenic liquid hydrogen (LH2) |
| Capacity (in gallons) | 535,000 gallons (2.0 million liters) |
| Capacity (in US gallons) | 146,000 US gal (550,000 L) |
| Capacity of Ares I second stage | 26,000 US gal (98,000 L) |
| Burn time | 480 seconds |
| Specific impulse | 455 seconds |
| Thrust at sea level | 5.45 MN |
| Thrust per SRB | 12.5 MN |
| Attachment points | One forward attachment point and one aft bracket to each SRB |
| Electrical connections | Two electrical umbilicals |
| Camera mount locations | Brackets attached to the shuttle |
Explore related products
What You'll Learn
- The Space Shuttle external tank (ET) contained liquid hydrogen fuel and liquid oxygen oxidizer
- The ET was the largest and heaviest element of the Space Shuttle
- The ET supplied fuel and oxidizer to the three RS-25 main engines
- The ET was jettisoned after main engine cut-off and broke up before re-entering Earth's atmosphere
- The ET had electrical umbilicals that carried power and signals between the tank, the orbiter, and the solid rocket boosters
The Space Shuttle external tank (ET) contained liquid hydrogen fuel and liquid oxygen oxidizer
The Space Shuttle external tank (ET) was an essential component of the Space Shuttle launch vehicle. It contained liquid hydrogen fuel and liquid oxygen oxidizer, which were supplied under pressure to the three RS-25 main engines during lift-off and ascent. The ET was the largest and heaviest element of the Space Shuttle when loaded. It consisted of three major components: the forward liquid oxygen (LOX) tank, the aft liquid hydrogen (LH2) tank, and the interconnecting structure that housed the pressurization and control equipment.
The liquid oxygen (LOX) tank held approximately 146,000 US gallons (550,000 litres) of oxidizer, while the liquid hydrogen (LH2) tank held about 629,340 kg (1,387,457 lb) of fuel. Together, these provided a significant amount of thrust, with a specific impulse of 455 seconds, resulting in 5.45 MN of thrust at sea level. The Super Lightweight Tank (SLWT) was the last and most advanced version of the ET, used with the STS.
The ET played a critical role in providing structural support for the attachment of the Space Shuttle Solid Rocket Boosters (SRBs) and the orbiter. It was connected to each SRB and the orbiter through multiple attachment points and bipods, ensuring stability during launch. Additionally, the ET featured electrical umbilicals that carried power, fluids, gases, and electrical signals between the tank, the orbiter, and the SRBs. These umbilicals also facilitated the transmission of video data through mounted cameras, even after the separation of the shuttle and the ET.
Despite its crucial function, the ET was designed to be discarded after use. It was jettisoned just over ten seconds after the main engine cut-off (MECO) and re-entered the Earth's atmosphere, breaking up before impact in the Indian or Pacific Ocean, away from shipping lanes. While there were proposals to reuse the ET, such as in a lunar habitat or as an orbital station, these ideas did not come to fruition. The retirement of the Space Shuttle program in 2011 marked the end of the ET's operational life.
