The weight of a fully fuelled and loaded Boeing 767 depends on the variant, with the 767-400ER being the heaviest in the family. The 767 is a wide-body, twin-engine jetliner that has become one of the most versatile and successful aircraft in commercial aviation. It offers a range of configurations and variants, making it adaptable for various market needs, from high-capacity passenger flights to freighter operations. The 767-400ER, with its raked wingtips and extended range, has a maximum design take-off weight (MTOW) of 450,000 lbs (204,116 kg). The lightest variant is the 767-200, with an MTOW ranging between 282,000 lbs (127,913 kg) and 315,000 lbs (142,882 kg). The weight of a fully fuelled and loaded 767 depends on various factors, including the number and type of seats, engines, payload, and required reserve fuel.
| Characteristics | Values |
|---|---|
| Maximum Takeoff Weight | 415,000 lbs (188,265 kg) |
| Operating Empty Weight | 200,100 lbs (90,775 kg) |
| Fuel Capacity | 26,055 gallons (98,730 liters) |
| Maximum Payload | 130,000 lbs (59,000 kg) |
| Typical Passenger Capacity | 200-300 passengers |
| Maximum Range | 6,385 nautical miles (11,825 km) |
| Wingspan | 156 ft (47.5 m) |
| Length | 180 ft 2 in (54.9 m) |
| Engine Type | Turbofan |
| Number of Engines | 2 |
| Engine Manufacturer | General Electric, Pratt & Whitney, or Rolls-Royce |
| Cruise Speed | 0.8 Mach (530-550 mph or 850-890 km/h) |
| Maximum Altitude | 40,000 ft (12,200 m) |
| First Flight | September 26, 1981 |
| Introduced | 1982 |
| Variants | 767-200, 767-300, 767-400, 767-300F (freighter) |
Explore related products
What You'll Learn
The maximum weight of a Boeing 767-400ER is 450,000 lbs
The Boeing 767 is a wide-body, twin-engine jetliner that has become one of the most versatile and successful aircraft in commercial aviation. It was first introduced in 1982 and has since been upgraded with advanced navigation, communication, and autopilot systems. The 767-400ER is the heaviest aircraft in the 767 family, with a maximum weight of 450,000 lbs (204,116 kg). This variant has the largest wingspan at 170 ft 4 in (51.92 m) and is equipped with raked wingtips to lower fuel burn.
The 767-400ER's maximum weight is significantly higher than other variants in the 767 family. For example, the 767-200 has an MTOW ranging from 282,000 to 315,000 lbs (127,913 to 142,882 kg), while the 767-300ER has an MTOW ranging from 380,000 to 412,000 lbs (172,365 to 186,880 kg). The higher weight of the 767-400ER allows it to carry heavier payloads and fly longer distances.
The increased gross weight of the 767-400ER and other variants has been a key factor in their appeal to freight operators. UPS and DHL Aviation placed orders for the 767-300F, leading Boeing to consider enhanced versions of the 767-200 and 767-300F with increased gross weights and improved fuel efficiency. The 767-400ER's range is between 3,820 and 5,500 nautical miles (7,070 to 10,185 km), which is slightly less than other variants due to its focus on increased capacity.
The maximum weight of an aircraft is crucial in determining its capabilities and limitations. The 767-400ER's maximum weight allows it to carry a substantial payload while still maintaining its long-range capabilities. This versatility has contributed to the 767's popularity among airlines and freight carriers, solidifying its place as one of the most successful aircraft in its class.
Fuel Weight: Gallon's Heavy Secret
You may want to see also
Explore related products
The 767-200ER has a higher maximum takeoff weight than the 767-200
The Boeing 767 is an American wide-body airliner developed and manufactured by Boeing Commercial Airplanes. The 767-200ER is an extended-range model that was first offered by Boeing in 1984. It has a higher maximum takeoff weight (MTOW) and greater fuel capacity than the 767-200.
The 767-200 typically seats 216 passengers and has a range of 3,900 nautical miles (7,200 km; 4,500 mi). In comparison, the 767-200ER seats 181 passengers and has a range of 6,590 nautical miles (12,200 km; 7,580 mi). The extended range of the 767-200ER is due to its increased fuel capacity and higher MTOW, which is up to 395,000 lb (179,000 kg).
The additional fuel capacity of the 767-200ER is achieved by using the center tank's dry dock to carry fuel. In contrast, the non-ER variant (the 767-200) uses what are called cheek tanks, which are two interconnected halves in each wing root with a dry dock in between.
The 767-200ER was the first 767 to complete a non-stop transatlantic journey and broke the flying distance record for a twinjet airliner in 1988. It has been popular with international airlines operating medium-traffic, long-distance flights.
The 767-200ER also has a slightly longer wingspan than the 767-200, which provides higher-altitude cruise performance and expansion room for future stretched variants. The 767's fuselage width is midway between that of the 707 and the 747 at 16.5 feet (5.03 m). This width allows for seven-abreast seating with two aisles and produces less aerodynamic drag than previous wide-body designs.
Wealth and Fuel: When Does Assistance Stop?
You may want to see also
Explore related products
The 767-400ER has the largest wingspan in the 767 family
The weight of a fully fuelled and loaded Boeing 767 depends on the variant. The 767 is a wide-body airliner developed and manufactured by Boeing Commercial Airplanes. The initial 767-200 variant entered service in 1982, followed by the extended-range 767-200ER in 1984. The 767-300 was launched in 1986, followed by the extended-range 767-300ER in 1988, and the freighter version, the 767-300F, in 1995.
The 767-400ER, which entered service in 2000, is an extended-range version of the original -200 and -300 models, with added payload and operating distance capability. The 767-400ER has a total length of 205.11 feet (62.5 metres) and a wingspan of 170.2 feet (51.9 metres). This wingspan is 14.3 feet (4.36 metres) greater than that of the 767-300 and is the largest wingspan in the 767 family. The increased wingspan provides higher-altitude cruise performance and added fuel capacity, allowing the 767-400ER to carry heavier payloads over longer distances.
The 767-400ER typically seats 245 passengers and has a range of 5,625 nautical miles (10,415 kilometres or 6,473 miles). Its maximum takeoff weight (MTOW) is 204,120 kilograms. The powerplants are 2 x P&W PW4062 (281.6 kN) or 2 x GE CF6-80C2B8F (282.5 kN).
The 767-400ER features a number of other improvements over previous 767 variants, including an updated cockpit, redesigned landing gear, and a 777-style Signature Interior. The addition of raked wingtips contributes to the increased wingspan, while the use of manufacturer-sanctioned winglets can further improve fuel efficiency by an estimated 6.5 percent.
In summary, the 767-400ER is an extended-range version of the 767 with increased payload and operating distance capability. Its larger wingspan provides improved performance and fuel capacity, making it well-suited for long-distance flights with heavier payloads. With its advanced features and improved performance, the 767-400ER offers enhanced capabilities and flexibility for airlines and operators.
Fuel System Cleaners: How Much is Too Much?
You may want to see also
Explore related products
The 767's fuel efficiency is improved by raked wingtips
The weight of a fully fuelled and loaded Boeing 767 depends on the variant in question. For example, the 767-200ER has a higher maximum takeoff weight (MTOW) of 395,000 lb (179,000 kg) compared to the initial 767-200. The 767-400ERX has an even higher MTOW of up to 465,000 lb (210.92 t).
Now, onto the 767's fuel efficiency and its relation to raked wingtips:
The 767-400ER was the first Boeing commercial airplane to use raked wingtips as a wingspan extension. These wingtips are highly swept back, extending the 767's original 156-foot wingspan to 170 feet, 4 inches (51.9 m). The 7-foot-8-inch (2.4 m) wing extensions are designed to increase the aerodynamic efficiency of the wing, providing more lift without lengthening the wing. This results in improved cruise efficiency and range.
The raked wingtips offer several advantages over traditional wing extensions or winglets. Firstly, they are lightweight and simple to integrate, bolting directly onto the existing wing structure without requiring additional modifications. This efficiency of design and economy of structure affords the 767-400ER more gate and taxiway flexibility, as it can use the same gates as smaller airplanes. Secondly, raked wingtips offer weight-reduction benefits compared to simply extending the conventional main wingspan. At high load factors, the raked wingtips experience less load and induce less loading on the outboard main wing. Additionally, the leading-edge sweep results in a more favourable centre of pressure location, reducing the bending moment on the inboard wing.
Raked wingtips have been shown to improve fuel efficiency in Boeing aircraft. The 777-300ER, for example, is expected to achieve a 2% fuel efficiency improvement with its raked wingtips, saving up to $140,000 in fuel costs per year per airplane, or 1.3 million pounds of fuel. This also has environmental benefits, reducing carbon dioxide emissions by 3.9 million pounds per year.
Ryse Fuel's Caffeine Content: How Much Is Too Much?
You may want to see also
Explore related products
The 767-200ER's range is due to extra fuel capacity
The 767-200 was designed to have a sufficient range to fly across North America or the northern Atlantic. The 767-200ER, on the other hand, is an extended-range model that can carry heavier payloads at greater distances. The 767-200ER's increased range is due to its extra fuel capacity and higher maximum takeoff weight (MTOW) of up to 395,000 lb (179,000 kg).
The additional fuel capacity is achieved by using the center tank's dry dock to carry fuel. The non-ER variant's center tank, known as cheek tanks, consists of two interconnected halves in each wing root with a dry dock in between. The center tank is also utilised in the -300ER and -400ER variants.
The 767-200ER was the first 767 to accomplish a non-stop transatlantic journey. On April 17, 1988, an Air Mauritius flight from Halifax, Nova Scotia to Port Louis, Mauritius, broke the flying distance record for a twinjet airliner, covering 8,727 nautical miles (16,200 km; 10,000 mi).
The 767-200ER has been favoured by international operators seeking smaller wide-body aircraft for long-haul routes, such as New York to Beijing. The model's ability to carry heavier payloads over longer distances has made it a popular choice for medium-traffic, long-distance flights.
In addition to the 767-200ER, Boeing has explored other variants with extended range capabilities, such as the 767-400ERX, which was offered in 2000 but later cancelled. The 767-400ERX was designed to have a strengthened wing, fuselage, and landing gear, allowing for a higher MTOW and improved takeoff performance.
Hydrogen Fuel Cells: Are They Worth the Investment?
You may want to see also
Frequently asked questions
The 767-200 has an MTOW (maximum takeoff weight) ranging between 282,000 lbs (127,913 kg) and 315,000 lbs (142,882 kg).
The 767-300ER has an MTOW of 380,000–412,000 lbs (172,365–186,880 kg).
The Boeing 767 can carry between 12,140 and 24,140 US gallons of usable fuel, depending on the variant.
