The 1994 Ford F-150 is a truck with the option of dual fuel tanks. This means that there are two fuel tanks, one at the front and one at the back, which can be switched between to maximise the distance that can be travelled without needing to stop for fuel. There is some debate over whether a dual-tank system has one or two fuel pumps, with some sources suggesting that there is only one fuel pump that serves both tanks, while others indicate that there is a separate fuel pump for each tank.
| Characteristics | Values |
|---|---|
| Number of fuel pumps | 1 |
| Number of fuel tanks | 2 |
| Capacity of the side tank on the long bed | 19 gallons |
| Capacity of the front tank on the dual tank long bed | 16 gallons |
| Capacity of the rear tank on the dual tank long bed | 18 gallons |
| Fuel pump mounting gasket | Premium Long-Life Grease XG-1-C or -K or equivalent meeting Ford specification ESA-M1C75-B |
| Fuel tank sending unit | 9155 |
Explore related products
What You'll Learn
Fuel pump replacement
The 1994 F-150 has dual fuel tanks, which means it has two fuel pumps. Replacing a fuel pump can be done by anyone with fair mechanical proficiency and a set of hand tools. However, it is recommended to have an assistant to facilitate the process. Here is a step-by-step guide on how to replace the fuel pumps in your 1994 F-150:
Preparation:
- Park your vehicle on a firm, level surface and engage the parking brake.
- Put on safety gear, including gloves and safety glasses.
- Ensure you have a safe workspace with good ventilation, away from any sources of sparks or open flames. Keep a fire extinguisher nearby.
- Gather all the necessary parts and tools before beginning the job.
- Check your fuel tank for leaks or other damage, as it is easier to replace it while it is out.
- Refer to your owner's manual to understand the specific procedures for your vehicle.
Removal of the Old Fuel Pump:
- Disconnect the negative battery cable.
- Relieve the fuel system pressure.
- Siphon or drain as much fuel as possible from the fuel tank.
- Disconnect the filler tube hose and the electrical connection to the pump.
- Support the fuel tank with a jack and a block of wood.
- Remove any retaining straps or bolts holding the tank in place.
- Carefully disconnect the wiring connections, fuel lines, and vent hoses before fully lowering the tank.
- Remove the old fuel pump from the tank.
Installation of the New Fuel Pump:
- Compare the new fuel pump with the old one to ensure you have the correct part.
- Install the new fuel pump in the fuel tank, following the manufacturer's instructions.
- Apply a light coating of premium long-life grease to the fuel pump mounting gasket to hold it in place.
- Install the fuel tank sending unit and pump carefully, ensuring that the fuel filter is not damaged.
- Position the tabs of the fuel tank sending unit and pump into the slots of the fuel tank.
- Hold the assembly in place and install the fuel pump locking retainer ring by rotating it clockwise until it stops against the retainer ring tab.
- Reinstall the fuel tank, following the appropriate configuration and tank location for your vehicle.
- Reconnect the fuel lines, wiring connections, vent tubes, and the fuel filler tube.
- Reconnect the negative battery cable.
Testing:
- Fill the tank with gas and go for a drive to verify that the new fuel pump is functioning properly.
- Listen for any unusual noises and check for fuel leaks.
- Refer to your service manual for specific instructions on testing the fuel pump.
Remember to work carefully and thoroughly, especially when dealing with flammable liquids and electrical systems. Always put your safety first.
