Dual fuel tanks in trucks are known as the primary and secondary fuel tanks. The primary tank channels fuel directly to the engine, while the secondary tank takes in fuel, depending on the fuel available in the primary tank. These tanks are connected by a single pipe, and a control module stops the operation of the fuel when the engine is turned off. The dual fuel tank system contains four filtering or screening devices that regulate the truck's fuel pressure. In some trucks, including modern ones, fuel is drawn from one tank and then the other, eventually evening out.
| Characteristics | Values |
|---|---|
| Number of tanks | 2 |
| Types of tanks | Primary and secondary |
| Function of primary tank | Channels fuel to the engine |
| Function of secondary tank | Takes in fuel, depending on the fuel available in the primary tank |
| Connection between tanks | A single pipe |
| Components | Fuel pump, fuel intake sock, filter screen, fuel filter assembly, shuttle selector valve, dual function reservoir (DFR) |
| Function of shuttle selector valve | Opens the return line to the tank when the fuel pressure on the shuttle diaphragm exceeds the opposing spring force |
| Function of dual function reservoir (DFR) | Operated by the low-pressure pump to allow fuel flow from the selected tank and block ports to and from the other tank |
| Fuel flow | Natural and direct in the series design; through two different fuel pipes that meet at a junction in the parallel design |
| Fuel pressure regulation | Through screens and filters |
| Fuel cranking | One of the issues with dual fuel tanks |
| Fuel transfer | One of the issues with dual fuel tanks |
| Other issues | Overload tank and tank selector |
