There are various ways to set up a system with two fuel tanks, each with their own advantages and disadvantages. One way is to keep the tanks separate and use a transfer pump to move fuel from one tank to another. Another method is to use a Y connector to join the supply lines of both tanks, allowing for equilibrium between the two tanks and a consistent fuel level. A third option is to install a dual-circuit ball valve to switch between the two tanks simultaneously. The chosen method depends on various factors, including convenience, safety, and the physics of fuel transfer.
Explore related products
What You'll Learn
Using a Y connector to join supply, return and vent lines
When installing two fuel tanks, a Y connector can be used to join the supply, return, and vent lines. This plumbing design allows for equilibrium between the two tanks, ensuring that the fuel level remains the same on both sides. This can be achieved by adding a tube between the two tanks at the lowest level, allowing them to maintain an equal amount of fuel.
The Y connector can be used to join the supply lines from both tanks, as well as the return and vent lines. This creates a single fuel supply from both tanks, effectively increasing the fuel capacity. For example, if each tank has a capacity of 20 gallons, the Y connector setup will allow the vehicle to utilise a 40-gallon fuel supply. The dash gauge will still indicate the same fuel level, just for the larger combined capacity.
It is important to consider the positioning of the tanks and the plumbing. If the tanks are at the same level, the Y connector setup should work without any issues. However, when installing the tanks on different sides of a vehicle, such as the passenger and driver sides, filling up both tanks can be cumbersome. It requires filling up one side, then turning the vehicle around to access the other side.
Additionally, when using a Y connector setup, it is crucial to ensure proper valving and switching between the two tanks. One option is to install a manual dual-port valve, such as the Groco FV-6-5038 bronze 6-port marine valve, which allows for switching between the tanks and can also manage the return lines. This valve can be mounted under the cab or on the floor between the driver's seat and the door for easy access.
Overall, by utilising a Y connector to join the supply, return, and vent lines, two fuel tanks can work in conjunction to provide a single, larger fuel supply while maintaining equilibrium in fuel levels between the tanks. This setup offers a convenient solution for increasing fuel capacity and managing fuel distribution in vehicles with multiple tanks. However, it is important to carefully consider the plumbing design, tank positioning, and valving to ensure a smooth and efficient fuel system.
