How Difficult Is Changing Fuel Pumps On A 94 Escort Wagon?

Fuel pump replacement is a common issue with the 1994 Ford Escort Wagon. The fuel pump is located underneath the rear seat. While it is possible to change the fuel pump yourself, it is a complex process that requires a range of tools and safety precautions. Before attempting to replace the fuel pump, it is important to consult a mechanic or a trusted online forum for detailed instructions and safety guidelines.

Disconnecting the battery and cold start valve

• Locate the fuel cut-off switch: The fuel cut-off switch is usually located in the trunk of the vehicle, often in the right rear shock/strut tower (quarter panel) area.
• Flip the tab on the fuel cut-off switch: Find the tab on the fuel cut-off switch and flip it up to the "off" position.
• Disconnect the battery: Before proceeding further, it is important to disconnect the battery to ensure safety and prevent any electrical issues.
• Remove the rear seat: This will provide access to the fuel pump and other components in the fuel system.
• Undo the fuel cap: By opening the fuel cap, you can relieve fuel tank pressure, which is an important safety measure.
• Remove the access cover and disconnect the fuel pump harness: Locate the access cover and carefully remove it. Then, disconnect the electrical harness that supplies power to the fuel pump.
• Disconnect the fuel lines: Carefully pull out the tabs that secure the fuel lines and disconnect them. It is important to tie them back and keep track of which line is which to avoid confusion during reassembly.
• Clean the area around the locking ring: Before proceeding, use a suitable cleaning agent to clean the area around the locking ring, ensuring no debris or dirt interferes with your work.
• Remove the locking ring: Using a hammer and a non-ferrous punch (such as aluminium, hardwood, or copper), carefully tap the locking ring counter-clockwise to loosen and remove it. The locking ring secures the fuel pump in place.
• Remove the fuel pump: With the locking ring removed, carefully wiggle the fuel pump out of the fuel tank, being cautious not to let any debris fall into the tank.

At this point, you have successfully disconnected the battery and accessed the fuel pump, which includes the cold start valve as part of the fuel system. You can now proceed with further repairs or maintenance on the fuel pump as needed. Remember to work safely and refer to a qualified mechanic if you have any doubts or concerns.

Clamping the fuel inlet hose

To clamp the fuel inlet hose, you will need to remove the rear seat of your 1994 Ford Escort Wagon. Undo the fuel cap to relieve the fuel tank pressure. Remove the access cover and disconnect the fuel pump harness. Pull out the tabs and disconnect the fuel lines, ensuring you tie them back and keep track of which line is which.

Now, clean the area around the locking ring. Using a hammer and a non-ferrous punch (aluminium, hardwood, copper, or any tough and non-sparking material), undo the locking ring by turning it counter-clockwise. Remove the pump from the tank, being careful not to let any debris fall into the tank. This will require some wiggling to get the pump out around the fuel level sending unit. Take your time and be patient as it will come out.

The entire fuel sending unit will need to be removed. The fuel pulsator mod is why your car dies on corners. If your car sputters with less than a quarter tank of fuel and is fine otherwise, or if you experience a huge loss of power or your car dies when taking on-ramps, exit ramps, or sharp corners, then this procedure is probably for you.

You can observe from the end picture how the grey seal is not sealing too well. As the pump moves back and forth in the tank, it distorts these seals, causing fuel pressure to bleed down. Once it gets bad enough, it will bleed enough pressure for you to feel anything from a lack of power to a complete stall.

You can observe in the picture how the author of the procedure originally had a zip tie wrapped around the fuel pump to restrain any excess movement. With the movement gone, the car ran much better, but not as well as it was about to.

The author of the procedure then went to their local parts store hoping to easily get a replacement. They managed to get a Carter part number, but the part was discontinued. Ford will only sell you the entire sending unit. As the author had just shelled out some money on a new fuel pump, they were not keen to spend double that on a sending unit from Ford.

The solution is to use hose! The pulsator acts as a vibration damper, essentially an accumulator for the fuel system to help reduce shock loads on the pump. As the fuel system is already equipped with a pressure regulator, which also helps reduce shock, the author of the procedure considered it redundant and saw no harm in replacing it with a piece of hose.

You have to be careful what kind of hose you use. Notice the yellow tinge/coating on the hose. This is because it is wax-impregnated fuel injection hose. The wax helps repel the gasoline and extend the rubber hose's life while in the tank. Regular rubber hose will degrade or go "skunky" after a few months when left submerged in fuel. This is 5/16" fuel injection hose rated at 65 psi, more than enough for stock applications. If you're running higher fuel system pressures than that, you probably know enough to get a higher-pressure hose for your application. A couple of clamps, and it's done.

Installation is the reverse of removal. Once you get the sending unit in and hooked up, you may want to hook the harnesses, fuel lines, and battery back up. Reset the fuel cutout switch and take it for a drive without the access panel or rear seat in. This will give you a visual indication if the tank ring seal is leaking or not. If it's good and dry, with the car off, disconnect the harness, reinstall the cover and rear seat, and you're good to go. If it leaks, re-check the tank seal to ensure it is seated properly, as it can be tricky to put in. If everything appears fine, you may need a new tank seal or new locking ring.

Disconnecting the inlet and outlet lines

Step 1: Prepare the Vehicle

Before beginning any work, ensure you have the necessary tools, including metric and SAE wrenches, small hose clamps or vise grips, and a bucket or container. Jack up the rear of your Escort and place it on secure jack stands on solid, level ground. This will give you access to the fuel pump, located underneath the rear seat. Open the hood and disconnect the vehicle's battery to prevent any accidents.

Step 2: Loosen Connections

Locate the cold start valve at the top of the fuel distributor and loosen its connection using a small wrench. Have a rag handy to absorb any fuel that may drain from this valve. If your vehicle has the K-Jetronic system, you will also need to loosen the connection of the fuel feed line where it runs into the warm-up regulator. Again, use a small wrench and a rag to catch any spilled fuel.

Step 3: Clamp the Fuel Inlet Hose

Use line clamps, vise grips, or similar tools to securely clamp the fuel inlet hose. This step is important to prevent fuel spillage when you disconnect the inlet and outlet lines from the fuel pump.

Step 4: Disconnect the Inlet and Outlet Lines

Place a container under the lines to catch any spilled fuel. Using a small wrench, carefully disconnect the inlet and outlet lines from the fuel pump. Be cautious as fuel may spill during this step. Once the lines are disconnected, cover or tape the ends to prevent dirt or dust from entering the fuel system.

Step 5: Disconnect the Electrical Connections

Before removing the fuel pump, disconnect all electrical connections. This will ensure that you can safely remove the pump without causing any damage to the electrical system.

By following these steps, you can successfully disconnect the inlet and outlet lines when changing the fuel pump on your 94 Escort Wagon. Remember to work cautiously and refer to a repair manual for additional information specific to your vehicle.

Disconnecting the electrical connections

Before beginning, ensure you have gathered all the necessary tools and safety equipment. You will need metric and SAE wrenches, small hose clamps or vise grips, a bucket or container, and rags to absorb any spilled fuel. It is also important to work in a well-ventilated area and keep a fire extinguisher nearby.

Now, let's get started:

• Jack up the rear of your Escort and securely place it on jack stands. It is crucial to ensure that the jack stands are on solid, level ground to prevent slippage and potential injury.
• Open the hood and disconnect the vehicle's battery. This is an important safety precaution when working on any electrical components.
• Locate the cold start valve at the top of the fuel distributor. Using a small wrench, loosen the connection. Have a rag ready to absorb any fuel that may drain from this valve.
• If your vehicle has the K-Jetronic system, you will also need to loosen the connection of the fuel feed line where it runs into the warm-up regulator. Again, use a small wrench and a rag to catch any spilled fuel.
• Clamp the fuel inlet hose securely to prevent fuel spillage. You can use line clamps, vise grips, or similar tools for this step.
• Now, we will move on to the fuel pump itself. Place a container under the inlet and outlet lines of the fuel pump to catch any fuel spillage.
• Using a small wrench, disconnect the inlet and outlet lines from the fuel pump. Be careful not to lose any small parts and cover or tape the ends of the lines to prevent dirt or dust from entering the fuel system.
• We have now reached the main task at hand—disconnecting the electrical connections on the fuel pump. Before doing so, it is important to ensure that the fuel pump is securely held in place. Loosen the bolt on the retaining bracket that holds the fuel pump and slide it out carefully. You can place the fuel pump in the container you used to catch fuel spillage to contain everything in one place for easy cleanup.
• At this point, the fuel pump should be disconnected from the vehicle. The next steps will involve reassembling the components and installing the new fuel pump.
• Position the new fuel pump in the place where you removed the old one. Ensure that the rubber sleeve around the new pump is properly in place to protect it.
• Tighten the bolt on the retaining bracket to secure the new fuel pump in place.
• Reconnect the electrical feed, inlet, and outlet lines to the new fuel pump.
• Remove the clamp from the fuel inlet hose once it is securely reconnected to the pump.
• Tighten the cold start valve at the fuel distributor or the fuel feed line at the warm-up regulator, depending on your vehicle's system.
• Lower the car and reconnect the battery.
• Start the Escort and carefully check for any fuel leaks.

Remember to consult a qualified mechanic or a professional repair guide if you are unsure about any steps or procedures. Working on a fuel system can be dangerous, so always prioritize your safety and the safety of those around you.

Removing the old fuel pump and installing the new one

To remove the old fuel pump and install a new one, follow these steps:

Firstly, jack up the rear of your Escort and place the car on jack stands. Ensure that the jack stands are secure and on solid, level ground. Next, open the hood and disconnect the vehicle's battery.

Now, you need to loosen the connection of the cold start valve at the top of the fuel distributor with a small wrench. Use a rag to absorb any fuel that spills. Depending on your fuel system, you may also need to loosen the connection of the fuel feed line where it runs into the warm-up regulator. Again, use a rag to soak up any spilled fuel.

Clamp the fuel inlet hose to prevent spillage, then disconnect the inlet and outlet lines from the fuel pump with a small wrench. Place a container under the lines to catch any fuel. Cover or tape the ends of the lines to prevent dirt or dust from entering the fuel system.

Disconnect the electrical connections on the fuel pump, then loosen the bolt on the retaining bracket holding the pump in place. Carefully slide the fuel pump out and place it in the container to catch any remaining fuel.

Now for the new fuel pump. Position the new pump where you removed the old one, ensuring the rubber sleeve around the pump is in place for protection. Tighten the bolt on the retaining bracket to secure the pump while you reassemble the other components.

Reconnect the electrical feed, inlet, and outlet lines, then remove the clamp from the fuel inlet hose. Tighten the cold start valve at the fuel distributor or the fuel feed line at the warm-up regulator.

Finally, lower the car, reconnect the battery, and start the engine to check for any fuel leaks.

This process will help you replace the fuel pump on your 1994 Ford Escort Wagon, improving fuel delivery and resolving any sputtering or skipping issues caused by a failing pump.
