Fuel Pressure Regulator Changes: A Universal Guide?

Fuel pressure regulators are a must-have for any EFI system, maintaining a steady fuel supply and adapting the fuel supply to the fuel demand. However, not all fuel pressure regulator changes are the same. There are different types of fuel pressure regulators, such as return style or bypass regulators, deadhead regulators, and PWM or pulse-width modulation fuel pressure control. The choice of regulator depends on various factors, including the type of fuel system, fuel pump, and target power level. Additionally, the compatibility of the regulator with the fuel injectors and the desired fuel pressure settings also play a role in the selection process.

Return style regulators

However, there are also some drawbacks to using return style regulators. They require extra plumbing, including additional hoses and fittings for the return line. They also cannot be used in some fuel systems, such as a nitrous system with multiple regulators set at different pressures.

Aeromotive offers a range of return style regulators, including the Universal Return Style Regulator, which is a dual-purpose regulator for EFI or carbureted and street or strip applications. It offers adjustable base pressure and is compatible with various fuel types, including gasoline, ethanol, alcohol, and diesel.

Deadhead regulators

Deadhead fuel pressure regulators are used to maintain a steady fuel supply during changes in fuel demand. They are designed to adjust the fuel supply to match the demand, ensuring that the injectors receive the correct amount of fuel.

The Procomp Electronics 3-12 psi Adjustable Universal Deadhead Fuel Pressure Billet Regulator in Red is currently unavailable on Amazon. This product is designed to regulate fuel pressure within a range of 3 to 12 psi. It is important to ensure that the correct fuel pressure regulator is selected for your specific vehicle's requirements.

The Aeromotive SS Dead-Head Regulator, available at Pegasus Auto Racing Supplies, operates within a similar pressure range of 5 to 12 psi. This regulator features 3/8 NPT threading and is constructed from stainless steel.

It is important to note that fuel pressure regulators are vehicle-specific, and it is recommended to consult a professional or refer to manufacturer guidelines before making any changes to your vehicle's fuel system.

Mechanical vs. electric fuel pumps

Mechanical and electric fuel pumps both have their own advantages and disadvantages, and the right choice depends on your vehicle and your needs.

Mechanical Fuel Pumps

Mechanical fuel pumps were the first type of fuel pump, standard for many years, before being overtaken by electric fuel pumps in the 1930s and 1940s. They are connected to the engine with a belt and use a piston to push fuel from the tank to the engine. There are two types: positive displacement and centrifugal. Positive displacement pumps are the most common, squeezing fuel through a small opening, while centrifugal pumps use centrifugal force to draw the fuel in and are usually reserved for high-pressure applications.

Mechanical fuel pumps are typically less expensive, easier to repair, and more durable than electric fuel pumps, making them a great option for those on a budget or whose vehicles must endure harsh conditions.

However, they are less efficient, more prone to failure due to having more moving parts, more difficult to install, and require more frequent maintenance and upkeep.

Electric Fuel Pumps

Electric fuel pumps use an electric motor to push fuel from the storage tank to the engine. They are usually located inside the fuel tank or very close to it and are turned on and off by the engine's computer.

Electric fuel pumps offer more efficient and consistent fuel delivery, resulting in better performance and lower emissions. They are also easier to install, provide faster start times, and require less maintenance, saving money over the life of the vehicle.

On the other hand, they tend to be more expensive, complex, and may require additional components to accommodate their higher power requirements. They also operate at higher temperatures, so cooling is necessary to prevent overheating and possible engine damage.

Both types of fuel pumps are still used in most cars and trucks today, but the majority of vehicles now use electric fuel pumps due to their efficiency and economy. When choosing between the two, it is important to consider factors such as cost, installation, efficiency, durability, and maintenance. Consulting a professional mechanic can help ensure the best decision for your vehicle.

Returnless systems

Returnless fuel systems, introduced in the mid-1990s, are similar to conventional systems but require careful handling to ensure proper function and full component life. Unlike conventional systems, returnless systems do not have a return line to return unused fuel from the engine to the tank. Instead, the fuel is picked up via the fuel screen sock at the bottom of the tank and routed to the fuel pump, which supplies the required fuel pressure and volume to the engine. The excess fuel is then directed back into the tank after passing through a pressure regulator.

The pressure regulator in a returnless system lacks a vacuum connection to the engine, so it maintains a steady pressure regardless of changes in engine operating conditions. The PCM (Powertrain Control Module) ensures the engine receives the right amount of fuel by making rapid changes in injector pulse width. On newer fuel systems, a pressure sensor informs the PCM of the system fuel pressure, allowing it to modify the pulse width to the fuel pump power supply and adjust system pressure and volume accordingly. These newer systems eliminate the need for a separate pressure regulator.

One advantage of older return-type fuel systems was the constant filtering of fuel, as it had to pass through the fuel filter during each trip to the engine. In returnless systems, the placement of the fuel filter can impact the system's longevity and ease of service and repair. The filter can be placed outside the tank, in front of the pump, or after the pressure regulator. Placing the filter outside the tank means that any unused and potentially contaminated fuel is not filtered until its first and only trip to the engine, which can lead to repeated trips through the pump and potential damage. Putting the filter in front of the pump protects it from contamination but makes replacement more difficult and can cause low fuel pressure and fuel boiling if the filter becomes clogged. Placing the filter after the pressure regulator allows for repeated filtering of unused fuel and easy replacement, as it can be placed on top of the tank.

Overall, fuel system cleanliness is crucial for returnless systems, as any remaining dirt can quickly damage new components.
