The AM 2300 gal fuel tank is a robust and reliable solution for diesel, gasoline, and biodiesel fuel storage and transportation. With a nominal capacity of 2378 gallons, this tank is constructed from high-quality carbon steel, ensuring durability and safety. The tank features a mechanical overfill prevention valve, a vent device with a flame arrestor mesh, and a mechanical float-operated tank contents gauge. It also includes a range of standard and optional fittings to cater to diverse fuel management needs. The AM 2300 gal fuel tank is an ideal choice for those seeking a robust and versatile fuel storage and transportation solution.
| Characteristics | Values |
|---|---|
| Nominal capacity | 2378 gallons |
| Tank total length | 12.82 ft |
| Tank total width | 6.89 ft |
| Tank total height | 7.20 ft |
| Tank total weight | 2094 lbs |
| Shipping | Not included |
| Material | Carbon steel quality S235JR |
| Rust prevention | Primed with a rust-preventing layer |
| Colour | White |
| Delivery | Pressure-tested and ready-to-use |
Explore related products
What You'll Learn
AM-TANK2300 specifications
The AM-TANK2300 is a robust and advanced solution for diesel, gasoline, and biodiesel fuel storage and transportation, offering a nominal capacity of 2378 gallons (8995 litres). This skid-mounted horizontal cylindrical tank is manufactured with high-quality carbon steel (S235JR) and features a watertight electro-welded design, ensuring durability and leak prevention.
External Dimensions:
- Total Length (including containment dike): 12.82 ft (3.91 m)
- Total Width (including containment dike): 6.89 ft (2.10 m)
- Total Height (including fuel transfer unit): 7.20 ft (2.20 m)
Safety and Maintenance Features:
- Mechanical overfill prevention valve: Interrupts fuel flow at 90% of the tank's geometric capacity to prevent overfilling.
- Vent device with flame arrestor mesh: Safeguards against potential explosions or fires.
- Mechanical float-operated tank contents gauge: Allows for easy monitoring of fuel levels with a planetary gear and adjustable scale in centimetres.
- Tank drainage point with a safety cap: Facilitates routine maintenance and cleaning.
- Suction point with check valve, strainer, and ball valve: Ensures controlled and filtered fuel extraction.
- Containment dike: Features lifting plates, a grounding connection point, and a drain plug for convenient maintenance and the option to fix the uprights of the roof system.
Additional Specifications:
- Tank Total Weight: 2094 lbs
- Duty Cycle: 20 minutes on/off
- RPM: 3450
- IP Rating: IP55
- Auto-Nozzle: A60
Installing a Second Fuel Tank: A Comprehensive Guide
You may want to see also
Explore related products
Shipping and manufacturing
The AM 2300 gal fuel tank is a robust and reliable solution for diesel, gasoline, and biodiesel fuel storage and transportation. With a nominal capacity of 2378 gallons, this tank offers advanced features that ensure safe and efficient fuel handling.
The AM 2300 gal fuel tank is manufactured with attention to detail and stringent quality standards. The tank is constructed using carbon steel of the highest grade, ensuring durability and corrosion resistance. The manufacturing process involves watertight electro-welding through a submerged arc welding technique, resulting in a robust and leak-proof structure.
To enhance its longevity, the tank is primed with a rust-preventing layer and finished with a coat of white paint. This protective coating not only safeguards against corrosion but also gives the tank a sleek and professional appearance.
When it comes to shipping, the AM 2300 gal fuel tank is delivered pressure-tested and ready for immediate use. The skid-mounted horizontal cylindrical design ensures stability during transportation, and the anti-roll supports provide added security.
The tank's overall dimensions are carefully considered for ease of shipping and installation. With a total length of 12.82 feet, a width of 6.89 feet, and a height of 7.20 feet (including the fuel transfer unit), the tank can be manoeuvred and positioned efficiently.
The weight of the AM 2300 gal fuel tank is approximately 2094 lbs, which is substantial yet manageable for standard shipping and installation procedures. This weight reflects the tank's sturdy construction and the inclusion of essential features.
During shipping, the tank is securely packaged and handled with care to ensure it reaches its destination in pristine condition. The manufacturers prioritize safe and timely delivery, ensuring that the tank is protected from potential damage during transit.
Jet Fuel Tank Maintenance: Expert Tips for Optimum Performance
You may want to see also
Explore related products
Rental options
Energy Rental Solutions CAT offers 2300-gallon fuel tanks for rent. These tanks are reliable, environmentally conscious, and efficient. The company aims to provide its customers with everything they need for a successful project.
ERS CAT also offers rental fuel tanks in several other sizes, including 550 gallons, 1000 gallons, and 1200 gallons. These tanks can be used for power generation or air compressors and come equipped with various features, such as distribution boxes, receptacle panels, circuit breakers, and fuses.
The 2300-gallon fuel tank offered by ERS CAT appears to be a popular option for those seeking rental fuel tanks. It is suitable for both generator fuel and air compressor applications.
While specific rental options and pricing information is not readily available, interested parties can contact Energy Rental Solutions CAT through their website for more details on renting their 2300-gallon fuel tanks. They also provide job opportunities and spec sheets for their products, including the 2300-gallon fuel tank.
Draining a Mastercraft Boat Fuel Tank: Step-by-Step Guide
You may want to see also
Explore related products
Safety features
The AM 2300 gal fuel tank is a skid-mounted horizontal cylindrical tank manufactured using carbon steel. It has a nominal capacity of 2378 gallons and measures 12.82 ft in length, 6.89 ft in width, and 7.20 ft in height.
Mechanical Overfill Prevention Valve
The tank is equipped with a mechanical overfill prevention valve that is calibrated to interrupt the fuel flow when the tank reaches 90% of its geometric capacity. This feature helps prevent overfilling and reduces the risk of fuel spills.
Vent Device with Flame Arrester Mesh
The vent device is designed with a flame arrestor mesh to prevent the entry of external ignition sources and reduce the risk of fire hazards.
Tank Drainage Point with Safety Cap
The tank has a designated drainage point that is secured with a safety cap. This feature facilitates routine maintenance and cleaning while ensuring that the tank's contents can be safely drained without risk of spills or accidents.
Suction Point with Check Valve, Strainer, and Ball Valve
The suction point is equipped with a check valve, strainer, and ball valve assembly. This setup helps regulate the flow of fuel, prevent backflow, and capture any contaminants or debris, ensuring the safe and efficient transfer of fuel.
Equipotential Grounding Point
The fuel tank provides an equipotential grounding point to establish an electrical connection to earth. This feature helps dissipate static electricity and reduce the risk of sparks or explosions, enhancing the overall safety of the fuel storage and handling process.
Containment Dike with Lifting Plates and Grounding Connection
The tank is equipped with a containment dike that includes lifting plates and a grounding connection point. This feature provides structural support, facilitates safe handling and transportation, and ensures that any potential spills or leaks are contained within the designated area.
Chiron Fuel Tank: Massive Capacity for Unmatched Performance
You may want to see also
Explore related products
Maintenance and cleaning
The AM 2300 gal fuel tank is a large tank designed for storing and transporting diesel, gasoline, and biodiesel fuel. It is made of carbon steel and has a rust-preventing layer. The tank is delivered pressure-tested and ready-to-use.
To ensure the longevity of your AM 2300 gal fuel tank, proper maintenance and cleaning are essential. Here are some detailed instructions to help you maintain and clean your fuel tank effectively:
Step 1: Regular Inspection
Regularly inspect your fuel tank for any signs of damage, corrosion, or leaks. Use a flashlight to look inside the tank, especially in dark conditions, to check for any debris, sludge, or rust accumulation.
Step 2: Drain and Clean
If you notice any contaminants or it's time for routine maintenance, start by draining the tank completely. This can be done through the tank drainage point with a safety cap, which is provided for routine maintenance and cleaning. Ensure that you follow the appropriate safety measures and procedures during the draining process.
Step 3: Cleaning Methods
There are several methods you can use to clean your fuel tank, depending on the level of contamination and your personal preferences:
- Rag and Stick Method: Use a rag attached to a long stick to wipe down the inside of the tank. You can also add clean fuel, roll it around, and then dump it out until you are satisfied with the cleanliness.
- Pressure Washing: If there is significant sludge or rust, consider using a pressure washer. Feed the pressure washer with diesel fuel, kerosene, or a combination of ZEP industrial purple cleaner degreaser and ZEP calcium, lime, and rust remover. Spray the solution into the tank and wash thoroughly. Ensure you have a drain at the bottom to remove the cleaning solution.
- Chain and Brush Method: Attach a small chain or brush to the end of a rod, which can be clamped to a battery drill. Use this to knock loose any crud or debris inside the tank. Once the crud is in suspension, pump it out or drain it.
- Fuel and Water Combination: If you have a drain at the bottom of your tank, you can use a combination of fuel and water to clean it. Drain and repeat this process until you are satisfied with the results.
Step 4: Refill and Test
After cleaning, refill your fuel tank with clean fuel. If you used water during the cleaning process, ensure that the tank is completely dry before refilling. Test the tank by filling it and checking for any leaks or issues.
Step 5: Filter and Maintenance
Regularly maintain your fuel filters by replacing the filter elements and using fuel treatments, such as Stanadyne fuel treatment, to ensure the fuel remains clean and free of contaminants. Additionally, consider investing in a double filter arrangement with a water filter and a separate regular filter to enhance fuel filtration.
By following these detailed steps and performing regular maintenance and cleaning, you can effectively maintain and clean your AM 2300 gal fuel tank, ensuring its optimal performance and longevity.
Fuel Tank Fill-Up: How Much Does It Cost?
You may want to see also
Frequently asked questions
The AM 2300 gal fuel tank is used for the storage and transportation of diesel, gasoline, and biodiesel fuel.
The AM 2300 gal fuel tank is made of carbon steel quality S235JR and is watertight electro-welded using the submerged arc welding process.
The dimensions of the AM 2300 gal fuel tank are:
- Length (including containment dike): 12.82 ft
- Width (including containment dike): 6.89 ft
- Height (including fuel transfer unit): 7.20 ft
